VTT has assessed the techno-economics of the production of renewable liquid transportation fuels from forest residues. The case studies focused on the production of four biofuels using a method based on pressurised fluidised-bed gasification. The fuels studied were methanol, dimethyl ether (DME), Fischer-Tropsch liquids and synthetic gasoline.
The results show that the production of renewable biofuels from lignocellulosic biomass, mainly bark and forestry residues, could achieve an energy efficiency of 50–67%, depending on the end-product and process conditions. Should the thermal energy produced as a by-product be exploited for district heat or industrial steam, for example, the overall efficiency from biomass to saleable energy products could reach 74–80%.
Based on the case studies, the research scientists estimated that once commercialised the technology can be used to produce liquid transportation fuel at the cost of 58–78 €/MWh. Converted into gasoline-equivalent price per litre, the estimated production cost would be 0.5–0.7 €/litre. The price of renewable solutions would thus be on a level with the current pre-tax price of fossil transportation fuels, and cheaper than existing imported biofuels.
Each case study design was based on a BTL plant with 300 MW capacity, the equivalent of a large district heating power plant. A biorefinery of this size could produce liquid transportation fuel for about 150 000 cars. The EU has set a target of 10% renewable energy content for the transportation sector by 2020. For Finland, the target is 20%.
After long-term development work, the technical functionality of the production process was verified through extensive testing at VTT test rigs as well as industrial piloting in Finland and in the US. The technology is now ready for its first commercial-scale demonstration. However, the first wave of these ground-breaking production plants requires significant public venture capital investment, for which planning has consequently been initiated at both Finnish and EU level.
According to the research results, the best efficiency and lowest production costs were achieved in the production of biomethanol. The risks related to the commercialisation of the synthesis technology were also estimated to be lower with the biomethanol production plant compared to the other options.
Methanol is an alcohol fuel that can be used in modern cars at maximum 3 vol-% content in combination with petrol or, as with ethanol, in high concentrations in FlexFuel cars designed for this purpose. Methanol can also be further converted to synthetic gasoline or used as renewable raw material in the manufacture of various chemicals and biomaterials.
The VTT publication can be found here
The above story is reprinted from materials provided by Technical Research Centre of Finland (VTT).
